Light Pattern
LED work light Angled
Recommended retail price€ 95
BriodLights LED work light has a unique movable mount that is suitable for both side and rear mounting. The work light is specially adapted for tractors and has a wide asymmetric light pattern. Delivered with 30 cm cable with 2-pin DT connector. IP68. ECE R10 approved.
E-Approved3 year function warranty
Technical Specifications
| SKU | 15210 |
|---|---|
| Weight | 0,8 kg |
| 1 Lux Distance | 144 m |
| Beam Pattern | Flood |
| Colour Temperature | 5700 K |
| Connection | DT |
| Housing Material | Aluminium |
| IP Rating | IP69K |
| Lamp Type | LED |
| Lens | PMMA |
| Lumen Measured | 4,400 lm |
| Operating Temperature | -40 °C to +60 °C |
| Power Consumption | 60 W |
| Nominal Current at 12 V | 5.5 A |
| Nominal Current at 24 V | 2.8 A |
| Theoretical Lumens | 5,600 lm |
| Total Diodes | 10 |
| Voltage | 9–36 V |
| WxHxD | 150 × 90 × 88 mm |
| EMC | R10 |
